Steel Slitting Line
Compatible with silo machine for spiral steel silo construction
As a company that specializes in providing spiral steel silo manufacturing solutions, we offer a range of metal processing machines to create ready-to-use steel strips for spiral silo construction. Steel slitting line is one of them we offer to maintain high precision of steel strips. Apart from storage silo production, this steel slitting line can also be used in various industries requiring narrow coil strips.
In the spiral silo construction, steel slitting line plays a crucial role in the early stages of the process. The steel slitting line carries out processes of master coil uncoiling, slitting and recoiling it into the desired width. Further, the process is suitable for various types of metal coil materials, including:
- Cold-rolled and hot-rolled carbon steel coils
- Silicon steel coils
- Tinplate
- Stainless steel coils
- Aluminum alloy coils
- Alloy steel coils
- Various metal coils materials with surface coatings.
The steel slitting line mainly consists of the following devices:
- Feeding trolley
- Uncoiling unit
- Straightening and leveling machine
- Metal shear
- Slitting machine
- Scrap winder
- Tension control
- Recoiling unit
- Unloading device
- Material: Z27 galvanized steel coils
- Coil thickness: 2.0mm - 6.0mm
- Coil width: less than or equal to 1500mm, converting 1500mm wide coils into steel strips with widths ranging from 40mm to 800mm (40mm≥D≥800mm).
-
Agricultural industry grain storage silos, oil silos, feed silos
-
Pharmaceutical industry pharma storage tanks
-
Brewing industry wine storage tanks
-
Construction industry aggregate silos, cement silos, fly ash silos, gypsum powder storage silos, calcined petroleum coke storage silos
-
Environmental protection industry wastewater storage tank
-
Automotive industry silo vehicles
Other industries: steel desulfurization storage silos, natural gas storage silos, fire water tanks, steel pipeline, and so on.
As a specialist manufacturer of spiral silo making machine, we use our steel slitting line in our customers’ spiral silo construction projects. We continuously improve machine performance based on construction experience, making our silo manufacturing equipment even more efficient.
